M-SERIES
M series represents high precision reduction gears TwinSpin of mini sizes. The first representative of the series is the size TS 50, and in the near future we plan to introduce even smaller TwinSpin gears that extend the M series.M series has retained all the qualities of the larger Spinea gears.M series includes a completely sealed gears and are filled with grease for long lifetime. This design of reduction gears allows the mounting of the load directly to the output flange or case without requiring additional bearings.
M系列代表微型尺寸的高精度減速機TwinSpin。 該系列的第一個代表是尺寸TS 50，並且在不久的將來我們計劃導入更小的TwinSpin減速機延伸M系列.M系列保留了Spinea減速機的所有品質.M系列包括完全密封，並充滿潤滑脂，使用壽命長。 減速機的這種設計允許將負載直接安裝到輸出法蘭或減速機本體，而不需要額外的軸承。
• small dimensions and compact design
• fully sealed series
• simple installation possibilities
• zero- backlash reduction gear
• very low mass
• very high power density
• deep groove ball output bearing with very low friction
• high performance of the reduction gear
• high precision
• high torsion rigidity
• high linearity of torsion chracteristics
• very low input inertia
• very good vibrations
• very low friction and high efficiency
•體積小，結構緊湊
•全密封系列
•簡單的安裝可能性
•零間隙減速齒輪
•重量輕
•高功率密度
•具有非常低摩擦的深溝球軸承
•減速機的高性能
• 高精準度
•高扭轉剛性
•扭轉特性為線性
•輸入慣量非常低
•非常低的振動
•非常低的摩擦和高效率
•全密封系列
•簡單的安裝可能性
•零間隙減速齒輪
•重量輕
•高功率密度
•具有非常低摩擦的深溝球軸承
•減速機的高性能
• 高精準度
•高扭轉剛性
•扭轉特性為線性
•輸入慣量非常低
•非常低的振動
•非常低的摩擦和高效率
